Apex keypads provide flexible and durable solutions for your access control system. With two-way intercoms, proximity card options, pinhole cameras, and custom language settings, Apex keypads are the most flexible and durable keypads available in self-storage.
One-year warranty
- Built-in surge and lightning protection
Rugged metal outdoor enclosures
Powder-coated to resist fading and chipping
Language support for 9 different languages
Anti-vandal metal keypad with backlit numbers
Customizable messages
High-resolution, 4-line display with 140-degree viewing angle
Click here or email us at sales@ptisecurity.com to learn more about our industry-leading access control products and innovative technology solutions.
Metal Keypad (15) Side Keypad (3) Metal Keyboard (16) Industrial Keyboard (11) Backlit Keyboard (6) Mini Keyboard (6) Black Keyboard (5) Desktop Keyboard (10) Waterproof Touch Keyboard (2) Waterproof Solution For Outdoor Application (7) Pointing Device (14) Numeric Keypad With LCM (1) Membrane Keyboard (2) Custom keyboard (2). Stainless Steel Mini 12 Keys Metal Numeric Keypad for Vending machine Back light Metal Numeric Keypad in 3x4 Matrix 12 Keys, Stainless Steel Keypad 15 Keys Rugged Access Kiosk Keypad Numeric, Metal Panel Mount Keypad Rugged Stainless Steel Industrial Numeric Keypad with 16 Keys for Check.
Custom-Molded Keypads
Download crs driver. We specialize in the production of custom-molded keypads, membrane keypads, rubber keypads, and silicone rubber keypads. If backlighting is required, we provide various backlighting styles ranging from LED (Light-Emitting Diode) to incandescent and LGF (Light Guide Film), a new technology that produces a bright, evenly illuminated custom keypad that possesses a good tactile feel.
The keypad is manufactured using a cast metal housing and is supplied with a choice of a metal mounting plate or a metal surface mounting box. This robust keypad is also backlit for ease of use in low lighting conditions. Installation – The keypad is wired as shown on the control unit label. The cable exits centrally from the back of the keypad. Waterproof Metal Keypad Security Vandal Proof Keypad For Vending Machine 1. 20 keys compact format IP67 dynamic water proof and vandal proof Stainless Steel industrial keypad 2. Industrial metal.
Custom-molded keypads can be assembled using a variety of materials, including epoxy, acrylic, polycarbonate, silicone and more. We also co-mold silicone with metal frames for a rubber keypad that is both rigid and pliable then ease the assembly into the final product.
Our innovative custom-molded keypads can be manufactured to accommodate a variety of products including audio/video equipment, calculators, MRI machines, medical equipment, and LCD watches.
Offering a range of styles such as dome, rubber, silicone, hard caps, and sheet metal, we have served a wide array of industries including aerospace, appliances and electronics. Creative modems driver download.
Contact Elite Technology today for more information about our premium custom-molded keypads, membrane keypads, and silicone rubber keypads.
Sample Products
Created with silicone molding material, this keypad features an opaque material and positive image printing. The ink used to print the keypad's graphics is a silicone-based ink that bonds to the silicone base material after post curing. Carbon pills on the bottom of each key allows the buttons to interact with a PCB in the final assembly.
Metal Keyboard
This keypad is molded with translucent silicone material, screened with the required graphic colors, then spray-painted with a silicone-based black ink. Laser etching is then performed to allow the colors to show when the keypad is backlit. Final process is coating the keypad to extend the life of the graphics.
As the name suggests this keypad has Polycarbonate tops permanently adhered to a silicone base material. The graphics, in this case, are clear except for the green send and red end keys. When back lit these clear graphics appear white. However, when the backlighting is not on, the graphics appear black. This particular version called for a very attractive blue plastic key top.
Metal Keyboard Tray
This keypad has the soft feel of TPU (Thermoplastic Polyurethane). This TPU film is formed using a co-molding process with silicone rubber. It is similar to IMD (In Mold Decorating) but has a softer feel than is available with PET films generally used in IMD keypads. TPU film cannot be formed with deep draws like PET films used in IMD keypads. Thus they are ideal for thin keypads used in small hand held products. The TPU material has superior abrasion resistance and is resistant to chemicals and UV lighting.
Custom Molded Keypad Specifications:
Metal Keyboard Drawer
| Industry Focus | • Aerospace • Appliance • Automotive • Commercial • Electronics • Energy • Food Processing • HVAC • Industrial • Marine • Medical • Military/Government • Packaging • Pharmaceutical • Restaurant |
| Intended Application | • Audio/Video • Calculators • Cameras • Copiers • Digital Meters/Gauges • Fax Machines • Fire Alarms • Handheld Games • LCD Watches • Medical Equipment • MRI Machines • Navigation Equipment • Security Systems • Test Equipment • Toys |
| Keypad Type | • Dome Array • Hard Caps • Rubber Keys • Sheet Metal Keypads |
| Keypad Keytops | • Acrylic • Epoxy • Glass • PET • Polycarbonate • Ultra Thin Polycarbonate |
| Keypad Material | • Plastic • Rubber • Silicone • Dual Durometer • Thermoplastic |
| Features & Technologies | • Abrasion Resistance • Backlit • Chemical Resistant • Custom Graphics/Silk Screening/Pad Printing • In-Mold Graphics • Laser Etched Graphics • Membrane Switches • Metal Domes • Metalized Look • Multiple Colors • Polished Surfaces • Resistant to Fluorescent Lighting • Textured Surfaces • UV Light Resistance |
| Surface | • 3D • Concaved • Flat |
| Keypad Coatings | • Parylene • Polyurethane (PU) • Silicone |
| Backlighting Style | • Incandescent • Light Emitting Diode (LED) • Flood Lighting • Narrow Viewing • Light Guide Film (LGF) • Electroluminescence Panel (ELP) • Woven Fiber Optic Mesh |
| Manufacturing Processes | • Compression Molding • LIM (Liquid Injection Molding) • Injection Molding • Insert Molding • Metal Frame • Vacuum Metalizing |
| Pill Conductor Sizes | • 1.5mm • 2.0mm • 2.5mm • 3.0mm • 3.5mm • 4.0mm • 4.5mm • 5.0mm • 5.5mm • 6.0mm • 6.5mm • 7.0mm • 7.5mm • 8.0mm • 9.0mm • 10.0mm |
| Base Thickness | Min. • .008 in • .2 mm |
| Wall Thickness | Min. • .008 in • .2 mm |
| Distance Between Keys | Min. • .110 in • 2.8 mm |
| Length & Width of Individual key | Min. • .126 in • 3.2 mm |
| Lighting Life (Manufacturers Specifications) | • LED= Around 50,000 Hours • ELP= 3,000-5,000 Hours to Half Brightness • Fiber Optics= 100,000 Hours (Depending on Type of Bulb Used as the Light Source) |
| Production Volume | Min. • 500 units • Mid Volume to High Volume |
| Typical Lead Times Available | Min. (Production) • 3 Weeks Max. (Production) • 4 Weeks |
| Industry Standards | • ISO - International Organization for Standardization • RoHS - Restriction Of Hazardous Substances (Compliant) • REACH (Compliant) |
| File Formats | AI (preferred) AutoCAD (DWG,DWZ) BMP • Bit Mapped Graphics DXF • Drawing Interchange Format, or Drawing Exchange Format GIF • Graphics Interchange Format IGES(Preferred) • Initial Graphics Exchange Specification, ANSI file format. JPG or JEPG • Joint Photographic Experts Group • Portable Document Format SolidWorks (SLDPRT,SLDDRW,SLDDRT) STEP • Standard for the Exchange of Product Model Data TIFF • Tagged Image File Format |
| Tolerances | Size(mm)(±) • 0-4.0 +/-0.10 • 4.0-6.3 +/-0.15 • 6.3-10.0 +/-0.20 • 10.0-16.0 +/-0.20 • 16.0-25.0 +/-0.25 • 25.0-40.0 +/-0.35 • 40.0-63.0 +/-0.40 • 63.0-100.0 +/-0.50 • 100.0-160.0 +/-0.7 • 160> +/-0.50 Size(Inch)(±) • 0-0.157 +/-0.004 • 0.157-0.248 +/-0.006 • 0.248-0.394 +/-0.008 • 0.394-0.630 +/-0.008 • 0.630-0.984 +/-0.010 • 0.984-1.575 +/-0.014 • 1.575-2.480 +/-0.016 • 2.480-3.397 +/-0.020 • 3.937-6.300 +/-0.028 |
